* TEMPERATURE RANGEFOPERATING 0?`40?, OPERATING TEMPERATURE:-20?~80?
* HOLD UP TIMEF16mS MINIMUM AT FULL LOAD & NOMINAL INPUT VOLTAGE
* DIELECTRIC WITHSTANDFINPUT/OUTPUT 1500 VAC FOR 60 SECOND INPUT TOFRAME GROUND 1500 VAC FOR 60 SECOND
* EFFICIENCYFTYPICAL >80% AT 115VAC, 20%~100% MAX LOAD
* POWER GOOD SIGNALFON DELAY 100mS TO 500mS
* OVER POWER PROTECTIONF110% ~ 160%
* OVER VOLTAGEPROTECTIONF+5V5.9V`6.7VA+12V13.0V`15.0VA+3.3V3.9V`4.3V SHORT
* SHORT CIRCUIT PROTECTIONF+5V, +3.3V, +12V, -12V, AUTO-RECOVERED:+5VSB
* OVER CURRENT PROTECTION: +3.3V: 27.5~37.5A, +5V: 27.5~37.5A, +12V:44~60A
* EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B
* SAFETY: TO MEET UL, CUL, TUV
* REMOTE ON/OFF CONTROL
THE POWER SUPPLY SHALL ACCEPT A LOGIC OPEN COLLECTOR LEVEL WHICHWILL DISABLE/ENABLE ALL THE OUTPUT VOLTAGE (EXCLUDE +5V STANDBY).
AS LOGIC LEVEL IS LOWCOUTPUTS VOLTAGE WERE ENABLEC AS LOGIC LEVEL ISHIGHCOUTPUTS VOLTAGE WERE DISABLE.
* N+1 REDUNDANCY FUNCTION
* HOT-SWAPPABLE FUNCTION
* CURRENT/BALANCE LOAD SHARING DESIGN
* +3.3V REMOTE SENSING
* ISOLATION: BUILT-IN IN POWER MODULE
* POWER FACTOR CORRENTION: ACTIVE (MEET IEC-1000-3-2)
* COOLING: 40mm DC FANS (one module)
* DIMENSIONF276(D)×101(W)×82(H) mm
$461.00
