Features:
? Specification compliance: Flex ATX v1.01? Forward converter circuit? High efficiency and reliability? Zero minimum load on 3.3V rail? Low ripple & noise? Super low noise fan control? Short circuit protection on all outputs? Over voltage protection? Over power protection? 100% hi-pot test? 100% burn in, high temperature cycled on/off? PFC harmonics compliance: EN61000-3-2 +A1 +A2
 Electrical Specifications:
? Input frequency: 50/60 Hz? Inrush current, cold start: 80A max.? Efficiency, at normal input voltage: > 80%? Dielectric withstand, input to frame/ground: 1800VAC, 1sec? Dielectric withstand, input to : 1800VAC, 1sec? Line regulation: +/-1% typical? Load regulation: +/-5% typical? Cross regulation: +/-5% typical? Ripple / noise: 1%? MTBF, full load@25Camb. : >100K hours? Power Factor Correction: Active PFC 99% typicalSafety: CUL, TUV, CB, CCC, BSMI, CE, FCC

Dimension: L5.9? x W3.2? x H1.6?
