Features:

? DIMENSION: D7.87" X W3.94" X H1.59"-Inch? COOLING: ONE 40mm DC FANS.? TEMPERATURE RANGE: Operation 0℃~45℃? HOLD UP TIME: 16ms at maximum load & normal input voltage? EFFICIENCY: TYPICAL >80% AT 115VAC, FULL LOAD.? ATX 12V / EPS 12V? POWER GOOD SIGNAL: PW-OK is power good signal and should be asserted high by the Power Supply to indicate that +5VDC and +3.3VDC output are above the under voltage thresholds of the Power Supply TTL. compatible signal out with 100ms to 500ms.? OVER POWER PROTECTION: The Power Supply shall shut down when output power exceeds 110﹪to 160﹪ of full load and require a power on cycle be performed by the operate? OVER VOLTAGE PROTECTION: Standard on +5.0V, set at 6.5VDC  0.75VDC? SHORT CIRCUIT PROTECTION: A short circuit placed between the DC return and the output shall cause no damage and the Power Supply shall shutdown.? EMI: FCC CLASS A, CISPR22 CLASS A.? AGENCY APPROVALS: TO MEET UL, CUL, TUV.? MTBF: 100,000 hours.

Connectors:

20+4 Pin X 1
P4 MB X 1
8-Pin X 1
Peripheral X 6
FDD X 1
SATA X 2
