Features |
Specification ? Temperature Range: Operating: 0C ~ +50C on full load; storage & shipping: -20C ~ +80C ? Humidity: 85% on operating, 95% on storage ? Dielectric Withstand: Primary frame ground 1800V AC for 2 second ? Efficiency: Typical up to 85% ? Rise time: Less than 20ms ? Hold-up Time: 16 ms minimum at nominal input voltage ? Power Good Signal: Power on delay time 100 ~ 500ms, off delay 1ms minimum (TTL and CMOS compatible) ? Leakage Current: Less than 3.5mA at 264Vac, 63Hz ? MTBF: 100,000 hours on maximum load at +25C Dimensions (LxWxH): 220x100x40.5mm /8.66x3.9x 1.6 inch |
|
Input Characteristics Input Range: 90 ~ 264Vac, Full Range Input Frequency: 47 ~ 63Hz Input Current: Max 8A @ 115Vac, 4.0A @ 230Vac Inrush Current: No Damage | |
|
Output Characteristics Output Voltage Minimum Load Normal Load Maximum Load Load Reg. Ripple & Noise +3.3V 0.5A 10A 20A 5% 50mV P-P +5V 1.0A 10A 20A 5% 50mV P-P +12V1 0.5A 8A 16A 5% 120mV P-P +12V2 1.0A 8A 16A 5% 120mV P-P +12V3 1.0A 8A 16A 5% 120mV P-P -12V 0A 0.25A 0.5A 10% 120mV P-P +5Vsb 0A 1.5A 3.0A 5% 50mV P-P *+3.3V and +5V total output not exceed 130W *The 12V1,2,3 total output shall not exceed 39A * Total output for this subject power supply is 500W | |
Dimensions: 8.66" x 3.9" x 1.6"
Connectors:
20/24 Pin X 1
8-Pin EPS MB X 1
4 pin 12V X 2
Peripheral X 3
FDD X 1
SATA X 2
