Dimensions (LxWxH): 190x81.5x40.5mm
7.48 x 3.2 x 1.6 inch
Sale price
$186.00
Regular price
$211.00
Specification
TemperatureRange: Operating: 0C ~ +50C on full load;
storage& shipping: -20C ~ +80C
Humidity:85% on operating, 95% on storage
DielectricWithstand: Primary frame ground 1800V AC for 2 second
Efficiency:Typical > 90%
Rise time: Less than 20ms
Hold-upTime: 16 ms minimum at nominal input voltage
PowerGood Signal: Power on delay time 100 ~ 500ms, off
delay1ms minimum (TTL and CMOS compatible)
LeakageCurrent: Less than 3.5mA at 264Vac, 50Hz
MTBF:100,000 hours on maximum load at +25C
Dimensions (LxWxH): 190x81.5x40.5mm
7.48 x 3.2 x 1.6 inch
Connectors:
20+4 Pin X 1
8 pin + 8 pin (4 pin + 4 pin)
Molex 4 pin X 2
FDD X 1
SATA X 4
