RM-3130 10+1 Total Bay 3U Rack Mount Case GHI-313
  • RM-3130 10+1 Total Bay 3U Rack Mount Case GHI-313
  • RM-3130 10+1 Total Bay 3U Rack Mount Case GHI-313
RM-3130 10+1 Total Bay 3U Rack Mount Case GHI-313
$250.00 $270.00

Should you want to squeeze 8 Hard Disk Driveswith Dual CD and one Floppy
into a 3U Case using a 12" x 10" Size motherboard, this 3U RM-3313 isthe answer.

Since it is a 3U Case, you will not have to worry about using Riser Cards and
such.  Heck, you can also use a 2 to 3 HD Cage in the dual 5.25 Space formore
HD spaces.  Ultimately, using the right combination of parts, the RM-3313GHI-313
can actually give you a total of 12 HD Bay.
Construction: Heavy Duty Cold Rolled Electroplated Steel
Motherboard Size: Support ATX M/B (Max. to 12" x 10.3")
Drive Bays: 2 x 5.25" Open, 1 x 3.5" Open, 7 x 3.5" HD, 1 Additional 3.5" HD Option
Power Supply: 2U Single or Redundant Power with 200mm-300mm Depth in Rear Chassis Installation
Cooling Units: 2 x 9cm + 1 x 6cm Ball-Bearing Fans (51/23.5 CFM/Each)
Filter: Removeable Filters
Expansion Slot: 7 x Full Length Slots
Indicators: LEDs for Power + (2 x HDD) + (3 x LAN) Activity
Buttons: Power On/Off & System Reset
Door(s): 1 x Front Door with Thumbscrew Lock
Dimensions: 19" x 5.2" x 20.7"
Weight:  36 lbs / 16kgs
Product Applications: High Capacity Data Storage Server in 3U Form Factory


  • Industrial standard 19" 2U metal chassis
  • Lockable front door
  • Two  5.25" visible + One 3.5" visible bays
  • Seven 3.5" Internal Bays behind Dual 9cm Front Intake Fan
  • Possible 8th Internal HD Space using bracket pictured below
  • 3U Case, Full ATX 7 Slot Access, No need for Slot Riser Card
  • Twin 9CM Front Intake Cooling fans for HD pre-installed
    •
  • Rear 6CM Exhaust Cooling fans pre-installed
  • Dimensions:  5.2"(H)  x  19"(W)  x  20.7"(D)
    •
