ProductIntroduction
Model Number
D-313SE-MATX
RoHS Compliance Version
Yes
Standard Drive Bays
3.5" Drives: 1
3.5" Drive (internal): 4
5.25" Drives: 2
Indicators
Power, HDD
Switches
Power, Reset
Supported PSU Type
PS2
Expansion Slots
4 (full height & up to 165mm deep withhdds installed)
Material of Front Bezel
Aluminum
Material of Handle
Aluminum
Material of Main Chassis
Zinc-Coated Steel
Color of Front Bezel
Black
Color of Main Chassis
Black
Front Connector
2x USB 2.0
Motherboard Size
9.6 x 9.6 (microATX, mini-ITX)
Optional Fan:
120mm x1, 80mm x1, 60mm x2
Dimensions (WxHxD)
19.00" x 5.25" x 16.86"
482.6 mm x 133.3 mm x 428.2 mm
Notes
- mounting internal hard drive in theexternal 3.5" bay location will cause the drive bay cover detached tothe hard drive cage.
$219.00
- Industrial Chassis with 15" in Depth
- Supports Front Access USB2.0 x2
- Power and HDD LED
- Power and Reset Switch
- Support ATX PS2 Power Supply
- Support 4 x Full Height Add-on Cards
3.5" Drive (internal): 4
5.25" Drives: 2
482.6 mm x 133.3 mm x 428.2 mm
