Specification:
Sale price
$336.00
Regular price
$425.00
Features & Benefits
- Tool-less installation on internal 2.5" HDD bays, add-on cardand fans
- Quick release cabinet mounting screws
- HDD Carrier for 2.5" or 3.5" drives
- Two internal 2.5" drive bays for OS mirroring
- Front access info tag for easy server management
- Horizontal 6Gb/s SAS & SATA backplane with smart fan control
- Air flow management baffle to prevent circulation
- Anti-vibration middle Fans
- Supports 1U single and redundant PSU
Specification:
-
Form Factor 1U M/B Form Factor Extended ATX (12? x 13?) Dimensions (Dx Wx H) 660 x 430 x 43.5 (mm), 26? x 16.9? x 1.7? Drive Bays Slim ODD：1
3.5" Hot-swap：4
Internal 2.5"：2
PSU Form Factor 1U Single or Redundant Indicators 1 x Power Status,
1 x HDD Activity,
2 x LAN Activity ,
1 x Fan Failure and Overheat (RPSU SKU)Front Buttons Power On/Off, Alarm Mute, System Reset, 2 x USB2.0 System Security NA Cooling Fans Middle: 40x28, 40x48 or 40x56 (up to 6) Expansion Slots 1x Full Height & Length HDD Backplane 6Gb/s SATA/SAS Metal Thickness 1.0mm
