Features:
1U,Single rail, built-in 17 or 19 TFT LCD with
8ports KVM switch
Supportcombo interface for connecting to PC ports
Support one local console plus one optionalremote
console(CAT5 or IP)
keyboard in 105 keys, with touch pad
Built-in rail self-locking device
Temperedglass protect LCD screen
No software required- EasyPC selection via Front
pushbuttons, Hot keys, On Screen Display
Support two layers password security protectionand
searchPC server name
Specification
| Chassis | External Chassis | Industrial Metal Frame or Aluminum frame |
| Display | LCD | 17, 19" TFT LCD |
| Resolution | 1280 x 1024 | |
| Color | 16.2 M colors | |
| Brightness | 300 Nits | |
| Contrast | 500:1 | |
| Viewing Angle | 160 H, 160 V | |
| Protection | Tempered Glass | |
| KVM Switch | Ports | 8 ports |
| Video Signal | VGA D-Sub 15 | |
| Keyboard Signal | Combo port (PS2 and USB) or PS2 | |
| Mouse Signal | Combo port (PS2 and USB) or PS2 | |
| Control Button | Port Switch | 8x front push button |
| LCD Control | 4x LCD control button | |
| Power | 1x Front Standby, 1x Rear Main | |
| Operating system | OS | DOS/Windows/Netware |
| SCO/Linux/HP Unix/Solaris | ||
| Input Peripheral | Keyboard | 105 Key Keyboard *Optional 117-Key for Sun System |
| Pointing Device | Integrated TouchPad | |
| Pointing Device Button | 2x Button *Optional 3x Button for Sun System | |
| Power | Power supply | 60W, 100VAC ~ 240VAC Auto Switching |
| Dimensions | Wx Hx D | 442.4x 44x 600mm |
| Weight | Net weight | 13 kg |
| Compliance | CE, FCC, UL, RoHS | |
