Easy Installation and Maintenance
4 x 80 mm hot-swap middle fans for easy maintenance 8 x 3.5" hot-swap HDD trays
Flexibility and Compatibility
Complies with Intel DP Xeon/ DP Nocona/ DP AMD Opteron/DP Dempsey server boards Ultra320 SCSI, SATA2/SAS backplane (4 x HDDs per backplane) 1 x front access USB2.0 port
Validated Thermal Solutions
2 x 80 mm,rear-mounted fans for optimal heat dissipation Optimized HDD interfaces to maximize internal airflow System Monitoring
Buzzer alarm for fan failure and overheat warning Reset switch to disable audible warning

Generality	Design Standard	EIA-RS310D
	Sheet Metal Material	SGCC
	Sheet Metal Thickness	1.2mm
	Plastic Material Type	ABS
Mother Board Support	Form Factor	EEB (12"X13")
Processor Support		DP Xeon (Intel) DP Nocona (Intel) DP Opteron (AMD)
Dimensions	mm (W x H x D)	430 x 132 x 660
	inch (W x H x D)	16.9" x 5.2" x 26"
Drive Bays	Driver Bay (External 3.5")	1
	Driver Bay (Internal 3.5")	1
	Hot-swap HDD Trays	12
	Slim CD-ROM	1
PSU Support	PSU Form	Single 2U/3U
	Max. Wattage	Redundant 760W
Front Panel	Switch/Controls	Power On/Off System Reset Alerm Reset
	Indicators	Power LED HDD Activity LED(x1) LAN Activity LED(x2)
	Access I/O	USB 2.0(x2)
Expansion Slots & Rear Window	Rear Window	Standard
	Slot Opening	7
	Riser Card	Optional
System Cooling Fans	Middle	4 x 80mm (T32) Fans
	Rear	2 x 80mm (T25) Fans
Backplanes	Backplane	SERIAL ATA SAS
