RM-2122 2U 2 Hot-Swappable SATA Trays Rackmount Case w/ Power Supply
RM-2122 2U 2 Hot-Swappable SATA Trays Rackmount Case w/ Power SupplyRM-2122 2U 2 Hot-Swappable SATA Trays Rackmount Case w/ Power Supply
RM-2122 2U 2 Hot-Swappable SATA Trays Rackmount Case w/ Power Supply
Model: RM-2122VM
389.00

Specifications
RM-2122 2U 2 Hot-Swappable SATA Trays Rackmount Case w/ Power Supply
  • Industrial Grade Aluminum Drive Tray Handle with iStarUSA Signature Design
  • Ultra Compact 15" Body Depth
  • Fiber Optical Drive Tray Status Indicator
  • Advance Thermal Cooling Design that Optimize Airflow
  • Single/MultiLane SATA, MultiLane SAS, and D-Sub Backplane Option
  • Front Access USB Connector
  • Power, HDD, Alarm Led, and Power ON/OFF, Alarm Rest Switch
  • RoHS Compliance
This case is a storage server rackmount chassis with hot-swappable drive trays. Not only the stylish look of its appearance, but the functionality, flexibility, and uncompromised performance makes V Series a new breed of storage server. As Serial technology became a more cost effective solution, we have taken a step forward to prepare the migration of new technology trend.
Model Number RM-2122
RoHS Compliance Version Yes
Standard Drive Bays
  • Hot-swap Drive:
  • 2xSATA
  • Slim CD Drive:
  • 1
  • 3.5" Drive (internal):
  • 2
Cooling Fan [Option] 2x40mm 1x90mm [1x40mm Blower]
Mainboard Size (inch) 12 x 10
Industry Standard EIA-RS310D
Materials Heavy-Duty Cold-Roll Steel
Material of Main Chassis Zinc-Plated with Bright Chromate
Material of Front Bezel Texture-Coated
Material of Handle Aluminum
Backplane SATA I/SATA II
Expansion Slots 3 x Full Height PCI Slots or 7 x Low Profile (Option)
Switches Power ON/OFF and System Reset
Indicators Power + Fan Failure + HDD LED
System Board Up to 12 x 10
Temperature 0°C (32°F) ~ 50°C (122°F)
Humidity 5% ~ 95% Non-Condensing
Dimensions (W x H x D) 19 x 3.5 x 15 inch
