Features
Complied with EPS12V and ATX12V standard
Active Power Factor Correction (PFC) meet EN61000-3-2
High efficiency and reliability
Compatible with European Union directive 2002/95/EC (Restriction onHazardous Substances).
Remote On/Off function
Internal 12V DC fan included
Noise Killer (Thermal fan speed control function)
Low noise and ripple
Output over voltage, short circuit, and over current protection
100% Hi-pot, ATE, and burn-in tested
Re-settable power shut down
Complies with FCC part 15 subpart J class B and CISPR 22 Class BApproved ?by UL 60950, CSA C22.2, TUV
Specification
Temperature Range: Operating 0°C ~ +40°C on full load; derate5W/°C from 40°C to 50°C
Storage & shipping -20°C ~ +80°C
Humidity: 5~95% on operating and storage
Dielectric Withstand: Primary to frame ground 1800V AC for 1 second
Efficiency: 80% min on 230AC/50Hz & 78% min on 115VAC/60Hz atfull load
Rise Time: Less than 20ms
Hold-up Time: 17ms minimum at nominal input voltage
Power Good Signal: Power on delay time 100 ms to 500 ms, off delay1ms minimum (TTL and CMOS compatible)
Leakage Current: Less than 3.5mA at 115VAC/60Hz
MTBF: 100,000 hours on maximum load at +25°C
Dimension (WxHxL): 150x86x140mm/5.9?x3.4?x5.5?inches
Connectors:
1 x 24 Pin
1 x 8 Pin
1 x 4 Pin
5 x 4 Pin IDE
2 x SATA
1 x 6 Pin PCI-Express
1 x 8 Pin (6+2) PCI-Express
1 x Floppy
Sale price
$189.00
Regular price
$219.00
